Coolberg Technical Details / Brandalı Frigo Technical Details

Side Walls: 6 mm insulated curtain

Front Wall: 85 mm

Back Doors: 85 mm

Roof: 50 mm

Floor: 125 mm

Chassis Neck: 160 mm

(A) 5th Wheel Height: 1120 mm

(B) Front Overhang: 1600 mm

(C) Rear Overhang: 3150 mm

(WB) Wheelbase (Distance between king pin and axle center): 7680 mm

(L) Overall Length: 13600 mm

(LA) Internal Length: 13300 mm

(F) Overall Width: 2550 mm

(E) Internal Width: 2470 mm

(HA) Overall Height: 4030 mm

(H) Internal Height: 2710 mm

(W) Axle Distance (between two axles): 1320 mm

King Pin Load / Axle Load / Total Load: 12000 - 24000 - 36000 kg

Tare Weight (without cooling unit): 7740 kg
